Volvo EX90 (2025–present) dimensions
16′ 6″ (198.3″)504 cm long and 77.3″196 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
41.7″106 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Electric
- Combined MPGe
- 81–98
- EV range
- 310 mi
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Tight fit · 17.7″45 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Too long · −6.3″16 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 65.7″167 cm
Typical US sizes; your city’s code may differ.
| Length | 198.3″504 cm |
|---|---|
| Width | 77.3″196 cm |
| Height | 68.7″174 cm |
| Wheelbase | 117.5″298 cm |
| Ground clearance | 8.5″22 cm |
| Seats | 7 |
| Cargo space | 11.0 cu ft311 L |
| Cargo, rear seats folded | 75.4 cu ft2,135 L |
| Curb weight | 5,930 lb2,690 kg(up to 6,135 lb2,783 kg) |
| Max towing | 4,850 lb2,200 kg |
Based on 17 trims, model years 2025–2026.
Quick answers
- How long is the EX90?
- 16′ 6″ (198.3″)504 cm.
- Will the EX90 fit in a standard 2-car garage?
- Yes. A 20 ft deep garage leaves 41.7″106 cm of room, enough to walk around it. Check your own garage.
- Does it fit a standard parking space?
- Yes. A 9 × 18 ft space leaves 17.7″45 cm of length.
- Will it clear a 7 ft garage door?
- Yes. At 68.8″175 cm tall it clears a 7 ft door by 15.2″39 cm (without a roof box).
- How wide is it with mirrors?
- About 86.3″219 cm: 77.3″196 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
- How much does the EX90 cost?
- The 2026 EX90 starts at $76,695 (MSRP, before destination and taxes). See all trims and prices below.
- How much can the EX90 tow?
- Up to 4,850 lb when properly equipped (best version; most trims are rated lower). Towing capacity of every EX90 version and what it can tow.
- How far can the EX90 go on a charge?
- Up to 305 miles (EPA range, best version). Cold weather and highway speeds reduce it.
2026 EX90 prices and engines
The 2026 EX90 starts at $76,695 (Single Motor Plus RWD) and goes up to $89,845 (Twin Motor Performance Ultra). Properly equipped, it tows up to 4,850 lb.
| Trim | Engine | HP | Drive | Economy | Tows | MSRP |
|---|---|---|---|---|---|---|
| Single Motor Plus | Electric · 92 kWh | 329 | RWD | 276 mi range | 3,307 lb | $76,695 |
| Twin Motor Plus | Electric · 106 kWh | 449 | AWD | 298 mi range | 4,850 lb | $79,995 |
| Twin Motor Plus | Electric · 106 kWh | 449 | AWD | 298 mi range | 4,850 lb | $80,495 |
| Twin Motor Ultra | Electric · 106 kWh | 449 | AWD | 305 mi range | 4,850 lb | $84,345 |
| Twin Motor Ultra | Electric · 106 kWh | 449 | AWD | 305 mi range | 4,850 lb | $84,845 |
| Twin Motor Performance Plus | Electric · 106 kWh | 670 | AWD | 298 mi range | 4,850 lb | $84,995 |
| Twin Motor Performance Plus | Electric · 106 kWh | 670 | AWD | 298 mi range | 4,850 lb | $85,495 |
| Twin Motor Performance Ultra | Electric · 106 kWh | 670 | AWD | 305 mi range | 4,850 lb | $89,345 |
| Twin Motor Performance Ultra | Electric · 106 kWh | 670 | AWD | 305 mi range | 4,850 lb | $89,845 |
Manufacturer's suggested retail prices for the 2026 model year, before destination fees, taxes and options.
