Rivian R1T (2022–present) dimensions
18′ 1″ (217.1″)551 cm long and 82.0″208 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Tight fit
22.9″58 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Electric
- Combined MPGe
- 63–87
- EV range
- 420 mi
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Too long · −1.1″3 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Too long · −25.1″64 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Tight fit · 46.9″119 cm
Typical US sizes; your city’s code may differ.
| Length | 217.1″551 cm |
|---|---|
| Width | 82.0″208 cm |
| Height | 78.2″199 cm |
| Wheelbase | 135.8″345 cm |
| Ground clearance | 8.7″22 cm |
| Seats | 5 |
| Cargo space | 22.8 cu ft646 L |
| Cargo, rear seats folded | 22.8 cu ft646 L |
| Curb weight | 7,148 lb3,242 kg |
| Max towing | 11,000 lb4,990 kg |
| Max payload | 1,764 lb800 kg(up to 2,116 lb960 kg) |
Based on 28 trims, model years 2022–2027.
Quick answers
- How long is the R1T?
- 18′ 1″ (217.1″)551 cm.
- Will the R1T fit in a standard 2-car garage?
- Only just: a 20 ft deep garage leaves 22.9″58 cm, not enough to walk around it comfortably. Check your own garage.
- Does it fit a standard parking space?
- Not quite: it overhangs a 9 × 18 ft space by 1.1″3 cm.
- Will it clear a 7 ft garage door?
- Yes. At 78.2″199 cm tall it clears a 7 ft door by 5.8″15 cm (without a roof box).
- How wide is it with mirrors?
- About 91.0″231 cm: 82.0″208 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
- How much does the R1T cost?
- The 2027 R1T starts at $79,990 (MSRP, before destination and taxes). See all trims and prices below.
- How much can the R1T tow?
- Up to 11,000 lb when properly equipped (best version; most trims are rated lower). Towing capacity of every R1T version and what it can tow.
- How far can the R1T go on a charge?
- Up to 420 miles (EPA range, best version). Cold weather and highway speeds reduce it.
2027 R1T prices and engines
The 2027 R1T starts at $79,990 (Premium AWD) and goes up to $115,990 (Quad). Properly equipped, it tows up to 11,000 lb.
| Trim | Engine | HP | Drive | Economy | Tows | MSRP |
|---|---|---|---|---|---|---|
| Premium | Electric · 108 kWh | 533 | AWD | 329 mi range | 7,700 lb | $79,990 |
| Premium | Electric · 140 kWh | 533 | AWD | 420 mi range | 7,700 lb | $86,990 |
| Performance | Electric · 140 kWh | 850 | AWD | 371 mi range | 11,000 lb | $100,990 |
| Quad | Electric · 140 kWh | 1025 | AWD | 374 mi range | 11,000 lb | $115,990 |
Manufacturer's suggested retail prices for the 2027 model year, before destination fees, taxes and options.
