Kia Carnival (2022–present) dimensions
16′ 11″ (203.0″)516 cm long and 78.5″199 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
37.0″94 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Gas, Hybrid
- Combined MPG
- 21–33
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Tight fit · 13.0″33 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Too long · −11.0″28 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 61.0″155 cm
Typical US sizes; your city’s code may differ.
| Length | 203.0″516 cm |
|---|---|
| Width | 78.5″199 cm |
| Height | 69.9″178 cm |
| Wheelbase | 121.7″309 cm |
| Ground clearance | 6.8″17 cm |
| Seats | 8 |
| Cargo space | 40.2 cu ft1,138 L |
| Cargo, rear seats folded | 145.1 cu ft4,109 L |
| Curb weight | 4,852 lb2,201 kg |
| Max towing | 3,500 lb1,588 kg |
| Max payload | 1,559 lb707 kg(up to 1,605 lb728 kg) |
Based on 42 trims, model years 2022–2027.
Quick answers
- How long is the Carnival?
- 16′ 11″ (203.0″)516 cm.
- Will the Carnival fit in a standard 2-car garage?
- Yes. A 20 ft deep garage leaves 37.0″94 cm of room, enough to walk around it. Check your own garage.
- Does it fit a standard parking space?
- Yes. A 9 × 18 ft space leaves 13.0″33 cm of length.
- Will it clear a 7 ft garage door?
- Yes. At 69.9″178 cm tall it clears a 7 ft door by 14.1″36 cm (without a roof box).
- How wide is it with mirrors?
- About 87.5″222 cm: 78.5″199 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
- How much does the Carnival cost?
- The 2027 Carnival starts at $37,490 (MSRP, before destination and taxes). See all trims and prices below.
- How far can the Carnival go on a full tank?
- Gas: about 400 miles (19-gallon tank, 21 MPG combined); Hybrid: about 630 miles (19-gallon tank, 33 MPG combined). Highway driving goes further, city driving less.
- How much can the Carnival tow?
- Up to 3,500 lb when properly equipped (best version; most trims are rated lower). Towing capacity of every Carnival version and what it can tow.
2027 Carnival prices and engines
The 2027 Carnival starts at $37,490 (LX FWD) and goes up to $53,590 (SX Prestige). Properly equipped, it tows up to 3,500 lb.
| Trim | Engine | HP | Drive | Economy | Tows | MSRP |
|---|---|---|---|---|---|---|
| LX | 3.5L V6 | 287 | FWD | 21 MPG | 3,500 lb | $37,490 |
| LXS | 3.5L V6 | 287 | FWD | 21 MPG | 3,500 lb | $39,490 |
| LXS | 1.6L I4 hybrid | 242 | FWD | 33 MPG | 2,500 lb | $41,490 |
| EX | 3.5L V6 | 287 | FWD | 21 MPG | 3,500 lb | $41,690 |
| EX | 1.6L I4 hybrid | 242 | FWD | 33 MPG | 2,500 lb | $43,690 |
| SX | 3.5L V6 | 287 | FWD | 21 MPG | 3,500 lb | $46,590 |
| SX | 1.6L I4 hybrid | 242 | FWD | 33 MPG | 2,500 lb | $48,590 |
| SX Prestige | 3.5L V6 | 287 | FWD | 21 MPG | 3,500 lb | $51,590 |
| SX Prestige | 1.6L I4 hybrid | 242 | FWD | 33 MPG | 2,500 lb | $53,590 |
Manufacturer's suggested retail prices for the 2027 model year, before destination fees, taxes and options.
