Volvo V90 (2017–present) dimensions
16′ 2″ (194.3″)494 cm long and 74.6″189 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
44.8″114 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Gas, Hybrid
- Combined MPG
- 24–27
- Trunk (EPA)
- 34.0 cu ft963 L
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Yes, it fits · 20.8″53 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Too long · −3.2″8 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 68.8″175 cm
Typical US sizes; your city’s code may differ.
| Length | 194.3″494 cm(up to 195.2″496 cm) |
|---|---|
| Width | 74.6″189 cm(up to 75.9″193 cm) |
| Height | 60.7″154 cm |
| Wheelbase | 115.8″294 cm |
| Ground clearance | 6.0″15 cm |
| Seats | 5 |
| Cargo space | 53.9 cu ft1,526 L |
| Cargo, rear seats folded | 69.0 cu ft1,954 L |
| Curb weight | 4,277 lb1,940 kg(up to 4,370 lb1,982 kg) |
| Max towing | 3,500 lb1,588 kg |
| Max payload | 950 lb431 kg |
Based on 33 trims, model years 2017–2026.
Quick answers
- How long is the V90?
- 16′ 2″ (194.3″)494 cm, up to 195.2″496 cm for the longest trim.
- Will the V90 fit in a standard 2-car garage?
- Yes. A 20 ft deep garage leaves 44.8″114 cm of room, enough to walk around it. Check your own garage.
- Does it fit a standard parking space?
- Yes. A 9 × 18 ft space leaves 20.8″53 cm of length.
- Will it clear a 7 ft garage door?
- Yes. At 60.7″154 cm tall it clears a 7 ft door by 23.3″59 cm (without a roof box).
- How wide is it with mirrors?
- About 84.9″216 cm: 75.9″193 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
- How much does the V90 cost?
- The 2026 V90 starts at $66,900 (MSRP, before destination and taxes). See all trims and prices below.
- How much can the V90 tow?
- Up to 3,500 lb when properly equipped (best version; most trims are rated lower). Towing capacity of every V90 version and what it can tow.
2026 V90 prices and engines
The 2026 V90 costs $66,900 (B6 Ultra). Properly equipped, it tows up to 3,500 lb.
| Trim | Engine | HP | Drive | Economy | Tows | MSRP |
|---|---|---|---|---|---|---|
| B6 Ultra | 2.0L I4 mild hybrid | 295 | AWD | 25 MPG | 3,500 lb | $66,900 |
Manufacturer's suggested retail prices for the 2026 model year, before destination fees, taxes and options.
