Volvo C40 (2022–2024) dimensions
14′ 7″ (174.8″)444 cm long and 73.7″187 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
65.2″166 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Electric
- Combined MPGe
- 87–107
- EV range
- 297 mi
- Trunk (EPA)
- 24.0 cu ft680 L
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Yes, it fits · 41.2″105 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Tight fit · 17.2″44 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 89.2″227 cm
Typical US sizes; your city’s code may differ.
| Length | 174.8″444 cm |
|---|---|
| Width | 73.7″187 cm |
| Height | 62.8″160 cm |
| Wheelbase | 106.4″270 cm |
| Ground clearance | 7.0″18 cm |
| Seats | 5 |
| Cargo space | 14.6 cu ft413 L |
| Cargo, rear seats folded | 49.0 cu ft1,388 L |
| Curb weight | 4,763 lb2,160 kg(up to 4,817 lb2,185 kg) |
| Max towing | 2,000 lb907 kg |
Based on 10 trims, model years 2022–2024.
Quick answers
- How long is the C40?
- 14′ 7″ (174.8″)444 cm.
- Will the C40 fit in a standard 2-car garage?
- Yes. A 20 ft deep garage leaves 65.2″166 cm of room, enough to walk around it. Check your own garage.
- Does it fit a standard parking space?
- Yes. A 9 × 18 ft space leaves 41.2″105 cm of length.
- Will it clear a 7 ft garage door?
- Yes. At 62.8″160 cm tall it clears a 7 ft door by 21.2″54 cm (without a roof box).
- How wide is it with mirrors?
- About 82.7″210 cm: 73.7″187 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
- How much does the C40 cost?
- The 2024 C40 starts at $53,600 (MSRP, before destination and taxes). See all trims and prices below.
- How much can the C40 tow?
- Up to 2,000 lb when properly equipped (best version; most trims are rated lower). Check the rating for the exact trim and hitch in the table below.
- How far can the C40 go on a charge?
- Up to 297 miles (EPA range, best version). Cold weather and highway speeds reduce it.
2024 C40 prices and engines
The 2024 C40 starts at $53,600 (Single Motor Core RWD) and goes up to $60,550 (Twin Motor Ultimate). Properly equipped, it tows up to 2,000 lb.
| Trim | Engine | HP | Drive | Economy | Tows | MSRP |
|---|---|---|---|---|---|---|
| Single Motor Core | Electric · 82 kWh | 248 | RWD | 297 mi range | 2,000 lb | $53,600 |
| Twin Motor Core | Electric · 78 kWh | 402 | AWD | 257 mi range | 2,000 lb | $55,350 |
| Single Motor Plus | Electric · 82 kWh | 248 | RWD | 297 mi range | 2,000 lb | $55,400 |
| Twin Motor Plus | Electric · 78 kWh | 402 | AWD | 257 mi range | 2,000 lb | $57,150 |
| Single Motor Ultimate | Electric · 82 kWh | 248 | RWD | 297 mi range | 2,000 lb | $58,800 |
| Twin Motor Ultimate | Electric · 78 kWh | 402 | AWD | 257 mi range | 2,000 lb | $60,550 |
Manufacturer's suggested retail prices for the 2024 model year, before destination fees, taxes and options.
