Nissan Titan (2015–2024) dimensions
20′ 3″ (242.7″)616 cm long and 79.5″202 cm wide (Crew Cab · S). Comes in 10 body styles.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Too long
3.4″9 cm longer than the garage
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Gas, Flex-fuel
- Combined MPG
- 14–18
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Too long · −27.4″70 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Too long · −51.4″131 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Very tight · 20.6″52 cm
Typical US sizes; your city’s code may differ.
Nissan Titan Crew Cab · S
| Length | 242.7″616 cm(up to 243.4″618 cm) |
|---|---|
| Width | 79.5″202 cm |
| Height | 78.0″198 cm |
| Wheelbase | 151.6″385 cm |
| Ground clearance | 8.1″21 cm |
| Seats | 6 |
| Curb weight | 6,986 lb3,169 kg(up to 7,061 lb3,203 kg) |
| Max towing | 9,390 lb4,259 kg(up to 12,314 lb5,586 kg) |
| Max payload | 2,590 lb1,175 kg |
Based on 27 trims, model years 2015–2020.
Nissan Titan Crew Cab · SL
| Length | 242.7″616 cm(up to 243.4″618 cm) |
|---|---|
| Width | 79.5″202 cm |
| Height | 78.9″200 cm |
| Wheelbase | 151.6″385 cm |
| Ground clearance | 9.1″23 cm |
| Seats | 5 |
| Curb weight | 6,667 lb3,024 kg(up to 7,452 lb3,380 kg) |
| Max towing | 9,390 lb4,259 kg(up to 12,310 lb5,584 kg) |
| Max payload | 2,590 lb1,175 kg |
Based on 27 trims, model years 2015–2020.
Nissan Titan Crew Cab · SV
| Length | 242.7″616 cm(up to 243.4″618 cm) |
|---|---|
| Width | 79.5″202 cm |
| Height | 78.0″198 cm |
| Wheelbase | 151.6″385 cm |
| Ground clearance | 8.1″21 cm |
| Seats | 6 |
| Curb weight | 7,152 lb3,244 kg(up to 7,215 lb3,273 kg) |
| Max towing | 9,390 lb4,259 kg(up to 12,310 lb5,584 kg) |
| Max payload | 2,590 lb1,175 kg |
Based on 27 trims, model years 2015–2020.
Nissan Titan Crew Cab · Platinum Reserve
| Length | 242.7″616 cm(up to 243.4″618 cm) |
|---|---|
| Width | 80.7″205 cm |
| Height | 78.9″200 cm |
| Wheelbase | 151.6″385 cm |
| Ground clearance | 9.1″23 cm |
| Seats | 5 |
| Curb weight | 6,415 lb2,910 kg(up to 7,480 lb3,393 kg) |
| Max towing | 9,390 lb4,259 kg(up to 12,310 lb5,584 kg) |
| Max payload | 2,590 lb1,175 kg |
Based on 25 trims, model years 2016–2020.
Nissan Titan King Cab · S
| Length | 230.5″585 cm |
|---|---|
| Width | 79.5″202 cm |
| Height | 77.7″197 cm |
| Wheelbase | 139.8″355 cm |
| Ground clearance | 8.1″21 cm |
| Seats | 6 |
| Curb weight | 6,860 lb3,112 kg(up to 6,901 lb3,130 kg) |
| Max towing | 9,250 lb4,196 kg(up to 12,510 lb5,674 kg) |
| Max payload | 1,630 lb739 kg(up to 2,710 lb1,229 kg) |
Based on 22 trims, model years 2015–2020.
Nissan Titan King Cab · SV
| Length | 230.5″585 cm |
|---|---|
| Width | 79.5″202 cm |
| Height | 77.7″197 cm |
| Wheelbase | 139.8″355 cm |
| Ground clearance | 8.0″20 cm |
| Seats | 6 |
| Curb weight | 5,660 lb2,567 kg(up to 7,057 lb3,201 kg) |
| Max towing | 9,310 lb4,223 kg(up to 12,510 lb5,674 kg) |
| Max payload | 1,640 lb744 kg(up to 2,710 lb1,229 kg) |
Based on 22 trims, model years 2015–2020.
Nissan Titan Regular Cab · S
| Length | 228.1″579 cm(up to 231.0″587 cm) |
|---|---|
| Width | 79.5″202 cm |
| Height | 75.1″191 cm(up to 77.3″196 cm) |
| Wheelbase | 139.8″355 cm |
| Ground clearance | 8.1″21 cm |
| Seats | 3 |
| Curb weight | 6,665 lb3,023 kg |
| Max towing | 12,640 lb5,733 kg(up to 12,710 lb5,765 kg) |
| Max payload | 1,940 lb880 kg(up to 2,990 lb1,356 kg) |
Based on 18 trims, model years 2017–2019.
Nissan Titan Regular Cab · SV
| Length | 228.1″579 cm(up to 231.0″587 cm) |
|---|---|
| Width | 79.5″202 cm |
| Height | 75.2″191 cm(up to 77.2″196 cm) |
| Wheelbase | 139.8″355 cm |
| Ground clearance | 8.1″21 cm |
| Seats | 3 |
| Curb weight | 6,810 lb3,089 kg |
| Max towing | 12,640 lb5,733 kg(up to 12,710 lb5,765 kg) |
| Max payload | 2,910 lb1,320 kg |
Based on 18 trims, model years 2017–2019.
Nissan Titan Crew Cab · PRO-4X
| Length | 243.6″619 cm(up to 244.4″621 cm) |
|---|---|
| Width | 80.7″205 cm |
| Height | 78.4″199 cm |
| Wheelbase | 151.6″385 cm |
| Ground clearance | 8.8″22 cm |
| Seats | 5 |
| Curb weight | 6,536 lb2,965 kg(up to 7,323 lb3,322 kg) |
| Max towing | 9,230 lb4,187 kg(up to 12,030 lb5,457 kg) |
| Max payload | 2,520 lb1,143 kg |
Based on 14 trims, model years 2015–2020.
Nissan Titan King Cab · PRO-4X
| Length | 231.3″588 cm |
|---|---|
| Width | 80.7″205 cm |
| Height | 78.1″198 cm |
| Wheelbase | 139.8″355 cm |
| Ground clearance | 8.7″22 cm |
| Seats | 5 |
| Curb weight | 7,113 lb3,226 kg(up to 7,158 lb3,247 kg) |
| Max towing | 9,130 lb4,141 kg(up to 12,510 lb5,674 kg) |
| Max payload | 1,510 lb685 kg(up to 2,560 lb1,161 kg) |
Based on 11 trims, model years 2015–2020.
Quick answers
- How long is the Titan?
- 20′ 3″ (242.7″)616 cm, up to 243.4″618 cm for the longest trim.
- Will the Titan fit in a standard 2-car garage?
- No. It's 3.4″9 cm longer than a 20 ft deep garage. Check your own garage.
- Does it fit a standard parking space?
- Not quite: it overhangs a 9 × 18 ft space by 27.4″70 cm.
- Will it clear a 7 ft garage door?
- Yes. At 78.0″198 cm tall it clears a 7 ft door by 6.0″15 cm (without a roof box).
- How wide is it with mirrors?
- About 88.5″225 cm: 79.5″202 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
