Mazda CX-5 (2013–2016) dimensions
Generation KE
14′ 11″ (179.3″)455 cm long and 72.4″184 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
60.7″154 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Gas
- Combined MPG
- 26–29
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Yes, it fits · 36.7″93 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Tight fit · 12.7″32 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 84.7″215 cm
Typical US sizes; your city’s code may differ.
| Length | 179.3″455 cm |
|---|---|
| Width | 72.4″184 cm |
| Height | 67.3″171 cm |
| Wheelbase | 106.3″270 cm |
| Ground clearance | 8.5″22 cm |
| Seats | 5 |
| Cargo space | 34.1 cu ft966 L |
| Cargo, rear seats folded | 65.4 cu ft1,852 L |
| Curb weight | 3,589 lb1,628 kg |
| Max towing | 2,000 lb907 kg |
| Max payload | 977 lb443 kg(up to 1,065 lb483 kg) |
Based on 22 trims, model years 2015–2016.
Quick answers
- How long is the CX-5?
- 14′ 11″ (179.3″)455 cm.
- Will the CX-5 fit in a standard 2-car garage?
- Yes. A 20 ft deep garage leaves 60.7″154 cm of room, enough to walk around it. Check your own garage.
- Does it fit a standard parking space?
- Yes. A 9 × 18 ft space leaves 36.7″93 cm of length.
- Will it clear a 7 ft garage door?
- Yes. At 67.3″171 cm tall it clears a 7 ft door by 16.7″42 cm (without a roof box).
- How wide is it with mirrors?
- About 81.4″207 cm: 72.4″184 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
- How much does the CX-5 cost?
- The 2016 CX-5 starts at $21,795 (MSRP, before destination and taxes). See all trims and prices below.
- How far can the CX-5 go on a full tank?
- About 430 miles (14.8-gallon tank, 29 MPG combined). Highway driving goes further, city driving less.
- How much can the CX-5 tow?
- Up to 2,000 lb when properly equipped (best version; most trims are rated lower). Check the rating for the exact trim and hitch in the table below.
2016 CX-5 prices and engines
The 2016 CX-5 starts at $21,795 (Sport FWD) and goes up to $29,870 (Grand Touring). Properly equipped, it tows up to 2,000 lb.
| Trim | Engine | HP | Drive | Economy | Tows | MSRP |
|---|---|---|---|---|---|---|
| Sport | 2.0L I4 | 155 | FWD | 29 MPG | 2,000 lb | $21,795 |
| Sport | 2.5L I4 | 184 | FWD | 29 MPG | 2,000 lb | $23,195 |
| Sport | 2.5L I4 | 184 | FWD | 29 MPG | 2,000 lb | $23,595 |
| Sport | 2.5L I4 | 184 | AWD | 26 MPG | 2,000 lb | $24,445 |
| Sport | 2.5L I4 | 184 | AWD | 26 MPG | 2,000 lb | $24,895 |
| Touring | 2.5L I4 | 184 | FWD | 29 MPG | 2,000 lb | $25,215 |
| Touring | 2.5L I4 | 184 | AWD | 26 MPG | 2,000 lb | $26,465 |
| Touring | 2.5L I4 | 184 | AWD | 26 MPG | 2,000 lb | $26,515 |
| Grand Touring | 2.5L I4 | 184 | FWD | 29 MPG | 2,000 lb | $28,220 |
| Grand Touring | 2.5L I4 | 184 | FWD | 29 MPG | 2,000 lb | $28,570 |
| Grand Touring | 2.5L I4 | 184 | AWD | 26 MPG | 2,000 lb | $29,470 |
| Grand Touring | 2.5L I4 | 184 | AWD | 26 MPG | 2,000 lb | $29,870 |
Manufacturer's suggested retail prices for the 2016 model year, before destination fees, taxes and options.
