Kia EV9 (2024–present) dimensions
16′ 5″ (197.2″)501 cm long and 77.9″198 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
42.6″108 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Electric
- Combined MPGe
- 78–89
- EV range
- 305 mi
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Yes, it fits · 18.6″47 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Too long · −5.4″14 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 66.6″169 cm
Typical US sizes; your city’s code may differ.
| Length | 197.2″501 cm |
|---|---|
| Width | 77.9″198 cm |
| Height | 69.1″176 cm(up to 70.1″178 cm) |
| Wheelbase | 122.0″310 cm |
| Ground clearance | 7.8″20 cm |
| Seats | 6(up to 7) |
| Cargo space | 22.0 cu ft623 L |
| Cargo, rear seats folded | 84.9 cu ft2,404 L |
| Curb weight | 5,714 lb2,592 kg(up to 5,886 lb2,670 kg) |
| Max towing | 5,000 lb2,268 kg |
Based on 15 trims, model years 2024–2026.
Quick answers
- How long is the EV9?
- 16′ 5″ (197.2″)501 cm.
- Will the EV9 fit in a standard 2-car garage?
- Yes. A 20 ft deep garage leaves 42.6″108 cm of room, enough to walk around it. Check your own garage.
- Does it fit a standard parking space?
- Yes. A 9 × 18 ft space leaves 18.6″47 cm of length.
- Will it clear a 7 ft garage door?
- Yes. At 70.1″178 cm tall it clears a 7 ft door by 13.9″35 cm (without a roof box).
- How wide is it with mirrors?
- About 86.9″221 cm: 77.9″198 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
- How much does the EV9 cost?
- The 2026 EV9 starts at $54,900 (MSRP, before destination and taxes). See all trims and prices below.
- How much can the EV9 tow?
- Up to 5,000 lb when properly equipped (best version; most trims are rated lower). Towing capacity of every EV9 version and what it can tow.
- How far can the EV9 go on a charge?
- Up to 305 miles (EPA range, best version). Cold weather and highway speeds reduce it.
2026 EV9 prices and engines
The 2026 EV9 starts at $54,900 (Light RWD) and goes up to $71,900 (GT-Line). Properly equipped, it tows up to 5,000 lb.
| Trim | Engine | HP | Drive | Economy | Tows | MSRP |
|---|---|---|---|---|---|---|
| Light | Electric · 76 kWh | 215 | RWD | 230 mi range | 2,000 lb | $54,900 |
| Light Long Range | Electric · 99 kWh | 201 | RWD | 305 mi range | 2,000 lb | $57,900 |
| Wind | Electric · 99 kWh | 379 | AWD | 283 mi range | 3,500 lb | $63,900 |
| Land | Electric · 99 kWh | 379 | AWD | 283 mi range | 5,000 lb | $68,900 |
| GT-Line | Electric · 99 kWh | 379 | AWD | 280 mi range | 5,000 lb | $71,900 |
Manufacturer's suggested retail prices for the 2026 model year, before destination fees, taxes and options.
