Honda Pilot (2023–present) dimensions
16′ 8″ (199.9″)508 cm long and 78.5″199 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
39.6″101 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Gas
- Combined MPG
- 20–22
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Tight fit · 15.6″40 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Too long · −8.4″21 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 63.6″162 cm
Typical US sizes; your city’s code may differ.
| Length | 199.9″508 cm(up to 200.4″509 cm) |
|---|---|
| Width | 78.5″199 cm |
| Height | 71.0″180 cm(up to 72.0″183 cm) |
| Wheelbase | 113.8″289 cm |
| Ground clearance | 7.3″19 cm |
| Seats | 8 |
| Cargo space | 18.6 cu ft527 L |
| Cargo, rear seats folded | 87.0 cu ft2,464 L |
| Curb weight | 4,660 lb2,114 kg(up to 4,722 lb2,142 kg) |
| Max towing | 5,000 lb2,268 kg |
Based on 45 trims, model years 2023–2026.
Quick answers
- How long is the Pilot?
- 16′ 8″ (199.9″)508 cm, up to 200.4″509 cm for the longest trim.
- Will the Pilot fit in a standard 2-car garage?
- Yes. A 20 ft deep garage leaves 39.6″101 cm of room, enough to walk around it. Check your own garage.
- Does it fit a standard parking space?
- Yes. A 9 × 18 ft space leaves 15.6″40 cm of length.
- Will it clear a 7 ft garage door?
- Yes. At 72.0″183 cm tall it clears a 7 ft door by 12.0″30 cm (without a roof box).
- How wide is it with mirrors?
- About 87.5″222 cm: 78.5″199 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
- How much does the Pilot cost?
- The 2026 Pilot starts at $42,395 (MSRP, before destination and taxes). See all trims and prices below.
- How far can the Pilot go on a full tank?
- About 390 miles (18.5-gallon tank, 21 MPG combined). Highway driving goes further, city driving less.
- How much can the Pilot tow?
- Up to 5,000 lb when properly equipped (best version; most trims are rated lower). Towing capacity of every Pilot version and what it can tow.
2026 Pilot prices and engines
The 2026 Pilot starts at $42,395 (Sport FWD) and goes up to $55,195 (Black Edition). Properly equipped, it tows up to 5,000 lb.
| Trim | Engine | HP | Drive | Economy | Tows | MSRP |
|---|---|---|---|---|---|---|
| Sport | 3.5L V6 | 285 | FWD | 22 MPG | 3,500 lb | $42,395 |
| Sport | 3.5L V6 | 285 | AWD | 21 MPG | 5,000 lb | $44,495 |
| EX-L | 3.5L V6 | 285 | FWD | 22 MPG | 3,500 lb | $44,695 |
| EX-L | 3.5L V6 | 285 | AWD | 21 MPG | 5,000 lb | $46,795 |
| TrailSport | 3.5L V6 | 285 | AWD | 20 MPG | 5,000 lb | $50,595 |
| Touring | 3.5L V6 | 285 | AWD | 21 MPG | 5,000 lb | $51,295 |
| Elite | 3.5L V6 | 285 | AWD | 21 MPG | 5,000 lb | $53,695 |
| Black Edition | 3.5L V6 | 285 | AWD | 21 MPG | 5,000 lb | $55,195 |
Manufacturer's suggested retail prices for the 2026 model year, before destination fees, taxes and options.
How it changed from the previous generation
- Length+3.4″9 cm bigger
- Width about the same
- Height+0.4″1 cm bigger
- Wheelbase+2.8″7 cm bigger
