GMC Canyon (2020–2022) dimensions
17′ 8″ (212.4″)539 cm long and 74.3″189 cm wide (Crew Cab · 5.1 ft bed). Comes in 3 body styles.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Tight fit
15.4″39 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Diesel, Gas
- Combined MPG
- 18–23
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Too long · −8.6″22 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Too long · −32.6″83 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Tight fit · 39.4″100 cm
Typical US sizes; your city’s code may differ.
GMC Canyon Crew Cab · 5.1 ft bed
| Length | 212.4″539 cm(up to 224.6″570 cm) |
|---|---|
| Width | 74.3″189 cm |
| Height | 70.6″179 cm |
| Wheelbase | 128.3″326 cm |
| Ground clearance | 8.2″21 cm |
| Seats | 5 |
| Curb weight | 4,456 lb2,021 kg(up to 4,546 lb2,062 kg) |
| Max towing | 7,600 lb3,447 kg(up to 7,700 lb3,493 kg) |
| Max payload | 1,481 lb672 kg(up to 1,531 lb694 kg) |
Based on 28 trims, model years 2020–2022.
GMC Canyon Extended Cab
| Length | 212.4″539 cm |
|---|---|
| Width | 74.3″189 cm |
| Height | 70.4″179 cm |
| Wheelbase | 128.3″326 cm |
| Ground clearance | 8.4″21 cm |
| Seats | 4 |
| Curb weight | 4,348 lb1,972 kg |
| Max towing | 7,000 lb3,175 kg |
| Max payload | 1,433 lb650 kg(up to 1,562 lb709 kg) |
Based on 12 trims, model years 2020–2022.
GMC Canyon Crew Cab · 6.2 ft bed
| Length | 224.6″570 cm |
|---|---|
| Width | 74.3″189 cm |
| Height | 70.5″179 cm |
| Wheelbase | 140.5″357 cm |
| Ground clearance | 8.1″21 cm |
| Seats | 5 |
| Curb weight | 4,555 lb2,066 kg |
| Max towing | 7,550 lb3,425 kg |
| Max payload | 1,475 lb669 kg |
Based on 8 trims, model years 2021–2022.
Quick answers
- How long is the Canyon?
- 17′ 8″ (212.4″)539 cm, up to 224.6″570 cm for the longest trim.
- Will the Canyon fit in a standard 2-car garage?
- Only just: a 20 ft deep garage leaves 15.4″39 cm, not enough to walk around it comfortably. Check your own garage.
- Does it fit a standard parking space?
- Not quite: it overhangs a 9 × 18 ft space by 8.6″22 cm.
- Will it clear a 7 ft garage door?
- Yes. At 70.7″180 cm tall it clears a 7 ft door by 13.3″34 cm (without a roof box).
- How wide is it with mirrors?
- About 83.3″212 cm: 74.3″189 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
- How much does the Canyon cost?
- The 2022 Canyon starts at $26,800 (MSRP, before destination and taxes). See all trims and prices below.
- How far can the Canyon go on a full tank?
- About 400 miles (21-gallon tank, 19 MPG combined). Highway driving goes further, city driving less.
- How much can the Canyon tow?
- Up to 7,700 lb when properly equipped (best version; most trims are rated lower). Check the rating for the exact trim and hitch in the table below.
2022 Canyon prices and engines
The 2022 Canyon starts at $26,800 (Elevation Standard RWD) and goes up to $45,000 (Denali). Properly equipped, it tows up to 7,700 lb.
| Trim | Body | Engine | HP | Drive | Economy | Tows | MSRP |
|---|---|---|---|---|---|---|---|
| Elevation Standard | Extended Cab | 2.5L I4 | 200 | RWD | 22 MPG | 7,000 lb | $26,800 |
| Elevation Standard | Crew Cab · 5.1 ft bed | 2.5L I4 | 200 | RWD | 22 MPG | 7,000 lb | $28,700 |
| Elevation | Extended Cab | 2.5L I4 | 200 | RWD | 22 MPG | 7,000 lb | $30,300 |
| Elevation | Crew Cab · 5.1 ft bed | 2.5L I4 | 200 | RWD | 22 MPG | 7,700 lb | $32,200 |
| Elevation Standard | Extended Cab | 3.6L V6 | 308 | 4WD | 19 MPG | 7,000 lb | $32,200 |
| Elevation | Crew Cab · 5.1 ft bed | 3.6L V6 | 308 | 4WD | 19 MPG | 7,600 lb | $37,300 |
| Elevation | Crew Cab · 6.2 ft bed | 3.6L V6 | 308 | 4WD | 19 MPG | 7,550 lb | $37,900 |
| AT4 | Crew Cab · 5.1 ft bed | 3.6L V6 | 308 | 4WD | 19 MPG | 7,600 lb | $38,400 |
| AT4 | Crew Cab · 6.2 ft bed | 3.6L V6 | 308 | 4WD | 19 MPG | 7,550 lb | $39,000 |
| AT4 | Crew Cab · 5.1 ft bed | 3.6L V6 | 308 | 4WD | 19 MPG | 7,600 lb | $40,200 |
| AT4 | Crew Cab · 6.2 ft bed | 3.6L V6 | 308 | 4WD | 19 MPG | 7,550 lb | $40,800 |
| Denali | Crew Cab · 5.1 ft bed | 3.6L V6 | 308 | RWD | 21 MPG | 7,000 lb | $41,200 |
| Denali | Crew Cab · 5.1 ft bed | 3.6L V6 | 308 | 4WD | 19 MPG | 7,600 lb | $44,700 |
| Denali | Crew Cab · 6.2 ft bed | 3.6L V6 | 308 | 4WD | 19 MPG | 7,550 lb | $45,000 |
Manufacturer's suggested retail prices for the 2022 model year, before destination fees, taxes and options.
How it changed from the previous generation
- Length−12.2″31 cm smaller
- Width about the same
- Height about the same
- Wheelbase−12.2″31 cm smaller
