Chevrolet Traverse (2009–2017) dimensions
17′ 0″ (203.7″)517 cm long and 78.5″199 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
36.3″92 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Gas
- Combined MPG
- 17–19
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Tight fit · 12.3″31 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Too long · −11.7″30 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 60.3″153 cm
Typical US sizes; your city’s code may differ.
| Length | 203.7″517 cm |
|---|---|
| Width | 78.5″199 cm |
| Height | 69.9″178 cm |
| Wheelbase | 118.9″302 cm |
| Ground clearance | 7.2″18 cm |
| Seats | 8 |
| Cargo space | 24.4 cu ft691 L |
| Cargo, rear seats folded | 116.3 cu ft3,293 L |
| Curb weight | 4,713 lb2,138 kg(up to 4,956 lb2,248 kg) |
| Max towing | 5,200 lb2,359 kg |
| Max payload | 1,764 lb800 kg |
Based on 26 trims, model years 2015–2017.
Quick answers
- How long is the Traverse?
- 17′ 0″ (203.7″)517 cm.
- Will the Traverse fit in a standard 2-car garage?
- Yes. A 20 ft deep garage leaves 36.3″92 cm of room, enough to walk around it. Check your own garage.
- Does it fit a standard parking space?
- Yes. A 9 × 18 ft space leaves 12.3″31 cm of length.
- Will it clear a 7 ft garage door?
- Yes. At 69.9″178 cm tall it clears a 7 ft door by 14.1″36 cm (without a roof box).
- How wide is it with mirrors?
- About 87.5″222 cm: 78.5″199 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
- How much does the Traverse cost?
- The 2017 Traverse starts at $28,700 (MSRP, before destination and taxes). See all trims and prices below.
- How far can the Traverse go on a full tank?
- About 400 miles (22-gallon tank, 18 MPG combined). Highway driving goes further, city driving less.
- How much can the Traverse tow?
- Up to 5,200 lb when properly equipped (best version; most trims are rated lower). Check the rating for the exact trim and hitch in the table below.
2017 Traverse prices and engines
The 2017 Traverse starts at $28,700 (LS Base FWD) and goes up to $44,045 (Premier). Properly equipped, it tows up to 5,200 lb.
| Trim | Engine | HP | Drive | Economy | Tows | MSRP |
|---|---|---|---|---|---|---|
| LS Base | 3.6L V6 | 281 | FWD | 18 MPG | 5,200 lb | $28,700 |
| LS | 3.6L V6 | 281 | FWD | 18 MPG | 5,200 lb | $31,300 |
| LS | 3.6L V6 | 281 | AWD | 17 MPG | 5,200 lb | $33,300 |
| LT | 3.6L V6 | 281 | FWD | 18 MPG | 5,200 lb | $34,100 |
| LT | 3.6L V6 | 281 | AWD | 17 MPG | 5,200 lb | $36,100 |
| LT | 3.6L V6 | 281 | FWD | 18 MPG | 5,200 lb | $36,650 |
| LT | 3.6L V6 | 281 | AWD | 17 MPG | 5,200 lb | $38,650 |
| Premier | 3.6L V6 | 288 | FWD | 18 MPG | 5,200 lb | $42,045 |
| Premier | 3.6L V6 | 288 | AWD | 17 MPG | 5,200 lb | $44,045 |
Manufacturer's suggested retail prices for the 2017 model year, before destination fees, taxes and options.
