Chevrolet Equinox (2018–2024) dimensions
15′ 3″ (183.1″)465 cm long and 72.6″184 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
56.9″145 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Gas, Diesel
- Combined MPG
- 24–32
- Trunk (EPA)
- 30.0 cu ft850 L
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Yes, it fits · 32.9″84 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Tight fit · 8.9″23 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 80.9″205 cm
Typical US sizes; your city’s code may differ.
| Length | 183.1″465 cm |
|---|---|
| Width | 72.6″184 cm |
| Height | 65.4″166 cm |
| Wheelbase | 107.3″273 cm |
| Seats | 5 |
| Cargo space | 29.9 cu ft847 L |
| Cargo, rear seats folded | 63.5 cu ft1,798 L |
| Curb weight | 3,274 lb1,485 kg(up to 3,682 lb1,670 kg) |
| Max towing | 1,500 lb680 kg(up to 3,500 lb1,588 kg) |
| Max payload | 1,190 lb540 kg(up to 1,240 lb562 kg) |
Based on 47 trims, model years 2018–2020.
How it changed from the previous generation
- Length−4.7″12 cm smaller
- Width about the same
- Height−3.9″10 cm smaller
- Wheelbase−5.2″13 cm smaller
