BMW X5 (2019–2026) dimensions
16′ 2″ (194.3″)494 cm long and 78.9″200 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
45.0″114 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Gas, Plug-in hybrid, Hybrid
- Combined MPG
- 15–25
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Yes, it fits · 21.0″53 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Too long · −3.0″8 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 69.0″175 cm
Typical US sizes; your city’s code may differ.
| Length | 194.3″494 cm(up to 195.0″495 cm) |
|---|---|
| Width | 78.9″200 cm(up to 79.3″201 cm) |
| Height | 68.7″174 cm(up to 69.5″177 cm) |
| Wheelbase | 117.1″297 cm |
| Ground clearance | 8.3″21 cm |
| Seats | 5 |
| Cargo space | 33.9 cu ft960 L |
| Cargo, rear seats folded | 72.3 cu ft2,047 L |
| Curb weight | 5,425 lb2,461 kg(up to 5,646 lb2,561 kg) |
| Max towing | 7,200 lb3,266 kg(up to 7,209 lb3,270 kg) |
| Max payload | 1,080 lb490 kg(up to 1,323 lb600 kg) |
Based on 38 trims, model years 2019–2026.
Quick answers
- How long is the X5?
- 16′ 2″ (194.3″)494 cm, up to 195.0″495 cm for the longest trim.
- Will the X5 fit in a standard 2-car garage?
- Yes. A 20 ft deep garage leaves 45.0″114 cm of room, enough to walk around it. Check your own garage.
- Does it fit a standard parking space?
- Yes. A 9 × 18 ft space leaves 21.0″53 cm of length.
- Will it clear a 7 ft garage door?
- Yes. At 69.5″177 cm tall it clears a 7 ft door by 14.5″37 cm (without a roof box).
- How wide is it with mirrors?
- About 88.3″224 cm: 79.3″201 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
- How much does the X5 cost?
- The 2026 X5 starts at $68,300 (MSRP, before destination and taxes). See all trims and prices below.
- How much can the X5 tow?
- Up to 7,209 lb when properly equipped (best version; most trims are rated lower). Check the rating for the exact trim and hitch in the table below.
2026 X5 prices and engines
The 2026 X5 starts at $68,300 (sDrive40i RWD) and goes up to $131,000 (Competition). Properly equipped, it tows up to 7,209 lb.
| Trim | Engine | HP | Drive | Economy | Tows | MSRP |
|---|---|---|---|---|---|---|
| sDrive40i | 3.0L I6 mild hybrid | 375 | RWD | 25 MPG | 5,952 lb | $68,300 |
| xDrive40i | 3.0L I6 mild hybrid | 375 | AWD | 25 MPG | 5,952 lb | $70,600 |
| xDrive50e | 3.0L I6 plug-in hybrid | 483 | AWD | 22 MPG | 7,209 lb | $76,000 |
| M60i | 4.4L V8 mild hybrid | 523 | AWD | 19 MPG | 5,952 lb | $93,600 |
| Competition | 4.4L V8 mild hybrid | 617 | AWD | 15 MPG | – | $131,000 |
Manufacturer's suggested retail prices for the 2026 model year, before destination fees, taxes and options.
How it changed from the previous generation
vs X5 2015–2018
- Length+1.1″3 cm bigger
- Width+2.6″7 cm bigger
- Height−0.7″2 cm smaller
- Wheelbase+1.6″4 cm bigger
