Toyota RAV4 (2013–2018) dimensions
Generation XA40
15′ 4″ (183.5″)466 cm long and 72.6″184 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
56.5″144 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Gas, Hybrid
- Combined MPG
- 24–32
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Yes, it fits · 32.5″83 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Tight fit · 8.5″22 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 80.5″204 cm
Typical US sizes; your city’s code may differ.
| Length | 183.5″466 cm |
|---|---|
| Width | 72.6″184 cm |
| Height | 67.1″170 cm(up to 67.5″171 cm) |
| Wheelbase | 104.7″266 cm |
| Ground clearance | 6.1″15 cm |
| Seats | 5 |
| Cargo space | 38.4 cu ft1,087 L |
| Cargo, rear seats folded | 73.4 cu ft2,078 L |
| Curb weight | 3,630 lb1,647 kg(up to 3,950 lb1,792 kg) |
| Max towing | 1,500 lb680 kg(up to 3,500 lb1,588 kg) |
| Max payload | 900 lb408 kg(up to 1,050 lb476 kg) |
Based on 44 trims, model years 2015–2018.
