Hyundai Santa Fe (2019–2023) dimensions
Generation TM
15′ 8″ (187.8″)477 cm long and 74.4″189 cm wide.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
46.9″119 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Gas, Hybrid, Plug-in hybrid
- Combined MPG
- 19–34
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Yes, it fits · 22.9″58 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Too long · −1.1″3 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 70.9″180 cm
Typical US sizes; your city’s code may differ.
| Length | 187.8″477 cm(up to 193.1″490 cm) |
|---|---|
| Width | 74.4″189 cm |
| Height | 67.1″170 cm |
| Wheelbase | 108.9″277 cm |
| Seats | 5(up to 7) |
| Cargo space | 35.9 cu ft1,017 L |
| Cargo, rear seats folded | 71.3 cu ft2,019 L |
| Curb weight | 3,735 lb1,694 kg(up to 4,178 lb1,895 kg) |
| Max towing | 5,000 lb2,268 kg |
| Max payload | 1,138 lb516 kg(up to 1,495 lb678 kg) |
Based on 28 trims, model years 2019–2020.
Quick answers
- How long is the Santa Fe?
- 15′ 8″ (187.8″)477 cm, up to 193.1″490 cm for the longest trim.
- Will the Santa Fe fit in a standard 2-car garage?
- Yes. A 20 ft deep garage leaves 46.9″119 cm of room, enough to walk around it. Check your own garage.
- Does it fit a standard parking space?
- Yes. A 9 × 18 ft space leaves 22.9″58 cm of length.
- Will it clear a 7 ft garage door?
- Yes. At 67.1″170 cm tall it clears a 7 ft door by 16.9″43 cm (without a roof box).
- How wide is it with mirrors?
- About 83.4″212 cm: 74.4″189 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
How it changed from the previous generation
- Length−5.3″13 cm smaller
- Width about the same
- Height about the same
- Wheelbase−1.3″3 cm smaller
