Ford Transit Connect (2015–2023) dimensions
15′ 10″ (189.7″)482 cm long and 72.2″183 cm wide (Minivan). Comes in 3 body styles.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Yes, it fits
50.0″127 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Gas, Flex-fuel
- Combined MPG
- 22–26
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Yes, it fits · 26.0″66 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Very tight · 2.0″5 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Yes, it fits · 74.0″188 cm
Typical US sizes; your city’s code may differ.
Ford Transit Connect Minivan
| Length | 189.7″482 cm(up to 190.0″483 cm) |
|---|---|
| Width | 72.2″183 cm |
| Height | 72.0″183 cm(up to 72.8″185 cm) |
| Wheelbase | 120.6″306 cm |
| Ground clearance | 6.0″15 cm |
| Seats | 2(up to 7) |
| Cargo space | 15.7 cu ft445 L |
| Cargo, rear seats folded | 104.2 cu ft2,951 L |
| Curb weight | 3,979 lb1,805 kg(up to 4,025 lb1,826 kg) |
| Max towing | 2,000 lb907 kg |
| Max payload | 1,350 lb612 kg(up to 1,620 lb735 kg) |
Based on 47 trims, model years 2015–2019.
Ford Transit Connect Cargo Van
| Length | 189.7″482 cm(up to 190.0″483 cm) |
|---|---|
| Width | 72.2″183 cm |
| Height | 72.8″185 cm |
| Wheelbase | 120.6″306 cm |
| Ground clearance | 6.3″16 cm |
| Seats | 2 |
| Cargo space | 128.6 cu ft3,642 L |
| Cargo, rear seats folded | 128.6 cu ft3,642 L |
| Curb weight | 3,689 lb1,673 kg |
| Max towing | 2,000 lb907 kg |
| Max payload | 1,610 lb730 kg |
Based on 24 trims, model years 2016–2020.
Ford Transit Connect Wagon
| Length | 189.7″482 cm(up to 190.0″483 cm) |
|---|---|
| Width | 72.2″183 cm |
| Height | 72.0″183 cm(up to 72.6″184 cm) |
| Wheelbase | 120.6″306 cm |
| Ground clearance | 6.4″16 cm |
| Seats | 5(up to 7) |
| Cargo space | 15.7 cu ft445 L |
| Cargo, rear seats folded | 104.2 cu ft2,951 L |
| Curb weight | 4,025 lb1,826 kg |
| Max towing | 2,000 lb907 kg |
| Max payload | 1,350 lb612 kg |
Based on 23 trims, model years 2016–2020.
Quick answers
- How long is the Transit Connect?
- 15′ 10″ (189.7″)482 cm, up to 190.0″483 cm for the longest trim.
- Will the Transit Connect fit in a standard 2-car garage?
- Yes. A 20 ft deep garage leaves 50.0″127 cm of room, enough to walk around it. Check your own garage.
- Does it fit a standard parking space?
- Yes. A 9 × 18 ft space leaves 26.0″66 cm of length.
- Will it clear a 7 ft garage door?
- Yes. At 72.8″185 cm tall it clears a 7 ft door by 11.2″28 cm (without a roof box).
- How wide is it with mirrors?
- About 81.2″206 cm: 72.2″183 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
